1. Exceptional Mobility for Frequent Relocation
The crawler cone crusher station is equipped with a tracked travel system that allows it to move freely across complex terrain without the need for additional transportation. This exceptional mobility makes it ideal for applications requiring frequent relocation, such as river regulation, cobblestone crushing, and construction waste disposal, significantly reducing site preparation time and logistics costs.
2. Advanced Crushing Performance for Secondary and Tertiary Stages
Designed specifically for secondary and tertiary crushing, the crawler cone crusher station delivers high-efficiency crushing with stable performance. The cone crusher utilizes the laminated crushing principle, ensuring uniform particle shape and excellent product quality. Finished product sizes can be flexibly adjusted according to customer requirements, making it suitable for a wide range of aggregate production needs.
3. Complete Integration and User-Friendly Operation
The crawler cone crusher station integrates feeding, crushing, screening, and material handling functions into a single compact unit. The complete equipment set includes a vibrating feeder, cone crusher, vibrating screen, and multiple discharge belts, all coordinated by an advanced control system. This integrated design simplifies operation and maintenance, reducing labor requirements and improving overall efficiency.
4. Low Operating Costs and High Economic Returns
Designed with durability and efficiency in mind, the crawler cone crusher station features robust components and advanced hydraulic systems that minimize wear and reduce maintenance needs. Its fuel-efficient operation and ability to produce multiple finished product sizes on-site significantly lower operating costs while delivering high economic returns for investors, making it a cost-effective solution for mobile crushing operations.
The crawler cone crusher station operates on the laminated crushing principle. This high efficiency cone crusher delivers superior performance for secondary and tertiary crushing.The electric motor drives the eccentric sleeve to rotate. The main shaft oscillates. The crushing cone moves closer to and farther from the fixed cone periodically.When the cone approaches the fixed cone, the gap narrows. Material is crushed by compression and shearing. The laminated design ensures inter-particle crushing. This improves efficiency and produces uniform particle shapes. The mobile cone crushing equipment produces high-quality aggregates.When the cone moves away, the gap widens. Crushed material falls by gravity. The cycle repeats continuously.The crawler crushing station features automatic discharge adjustment. Operators control product size precisely. The hydraulic system enables quick adjustments.If uncrushable material enters, the release system activates. The cone lifts temporarily. The object passes without damage. The cone returns to normal position. The hydraulic cavity cleaning clears blockages quickly. This minimizes downtime.The construction waste crusher processes concrete and debris on-site. The cobblestone crushing plant handles hard materials efficiently. The tracked system provides excellent mobility. It travels across complex terrain without extra transport.Track-mounted crusher specifications include robust frames and wear-resistant liners.
*La capacidad de producción variará en función de los distintos materiales, tamaño de alimentación y otros factores.
| LWH Size(mm) | 17000×3300×3700 | 16400×2950×3600 | 17800×3500×3750 | 17400×3300×3800 | 22000×3750×4100 | 20000×3500×3800 | |
| Belt Feeder | Model | B1000×7000 | B1000×7000 | B1000×7000 | B1000×7000 | B1200×8000 | B1200×8000 |
| Volume(m³) | 5 | 5 | 5 | 5 | 3 | 3 | |
| Feeding Height(mm) | 2580 | 2580 | 2580 | 2580 | 2680 | 2680 | |
| Motor Power(kW) | 11 | 11 | 11 | 11 | 15 | 15 | |
| Cone Crusher | Model | HP200 | HP200 | HP300 | HP300 | HP400 | HP400 |
| Motor Power(kW) | 160 | 160 | 250 | 250 | 315 | 315 | |
| Main Discharge Belt | Size(mm) | B1000×9500 | B1000×10000 | B1000×9500 | B1000×10000 | B1200×12000 | B1200×10000 |
| Discharge Height(mm) | 2800 | 2500 | 2800 | 2500 | 2900 | 2800 | |
| Motor Power(kW) | 11 | 11 | 11 | 11 | 15 | 15 | |
| Checkscreen | Model | 2YKR1435 | —— | 2YKR1435 | —— | 2YKR1545 | —— |
| Motor Power(kW) | 2×3.7 | —— | 2×3.7 | —— | 2×5.5 | —— | |
| Discharge under sieve Belt 1# | Size(mm) | B1200×6500 | —— | B1200×6500 | —— | B1200×6500 | —— |
| Discharge Height(mm) | 2600 | —— | 2600 | —— | 2600 | —— | |
| Motor Power(kW) | 7.5 | —— | 7.5 | —— | 7.5 | —— | |
Contáctenos rellenando el formulario o por Email: sales@zxcrusher.com
Original mantles, concaves, and eccentric bushings ensure perfect fit and long service life for your high efficiency cone crusher.
Our team provides installation guidance, operation training, and troubleshooting to keep your crawler crushing station running smoothly at any site.
Global parts network ensures rapid supply of genuine components for all models like LTH200, LTH300, and LTH400, minimizing downtime and production loss.
We provide comprehensive support throughout the entire lifecycle of your equipment. Our service approach ensures long-term reliability and optimized performance for every project.
