1.Superior Mobility & Quick Deployment
The
mobile cone crusher features a wheel-mounted design that enables
seamless transport between job sites without complex foundation work. It
can be operational within hours of arrival, significantly reducing
project lead times. Whether you are working in mining, quarrying, or
construction waste recycling, this equipment delivers exceptional
flexibility.
2.Integrated Design for High Efficiency
The
mobile cone crusher integrates feeding, crushing, screening, and
conveying functions into a single compact unit, eliminating the need for
additional support equipment. The intelligent automation system
monitors operation parameters in real time, ensuring optimal performance
while reducing fuel consumption and labor requirements.
3.Advanced Crushing Performance
Designed
specifically for secondary and tertiary crushing stages, the mobile
cone crusher delivers high efficiency and stable performance. The
automatic discharge opening adjustment and wear monitoring system
minimize downtime. The laminated crushing principle ensures uniform
particle shape and excellent product quality, making it ideal for
high-end construction projects and concrete production.
4.Cost-Effective On-Site Processing
By
processing material directly at the job site, the mobile cone crusher
eliminates costly material transport, reducing logistics expenses by up
to 50%. Its modular configuration allows flexible switching between jaw,
cone, and impact crusher units to match different material
characteristics and production requirements.
The mobile cone crusher operates on the principle of laminated crushing. The electric motor drives the eccentric sleeve to rotate through a belt drive and coupling, causing the main shaft to oscillate and move the crushing cone closer to or farther away from the fixed cone in a periodic motion.
When the crushing cone approaches the fixed cone, the gap narrows. Material in the crushing chamber is subjected to compression, bending, and shearing forces. The laminated crushing design means material is crushed not only by the cone surfaces but also by pressure between particles themselves, significantly improving efficiency and producing uniform particle shapes with excellent cubicity.
When the crushing cone moves away, the gap widens and crushed material meeting size requirements falls by gravity. This cycle repeats continuously.
The mobile cone crusher features automatic discharge opening adjustment for precise product size control. If uncrushable material such as tramp iron enters, the spring or hydraulic release system allows the cone to lift temporarily, letting the object pass without damage, then automatically returns to normal position. The hydraulic cavity cleaning system quickly clears blockages, minimizing downtime. This makes the mobile cone crusher ideal for secondary and fine crushing in mining, aggregate production, and recycling.
*La capacidad de producción variará en función de los distintos materiales, tamaño de alimentación y otros factores.
| Mobile Cone Crusher | Model | Max. Feeding size (mm) | Capacity (t/h) | Power (kw) | Overall dimensions (L*W*H)(mm) | Weight (t) |
| SY3Y154CS0917 | PSGB0917 | 150 | 59-163 | 75 | 13305*3227*6470 | 31 |
| 3YA1548 | 15 | |||||
| B500*7.6 | 3 | |||||
| SY3Y184CS1321 | PSGB1321 | 178 | 132-253 | 160 | 12799X3778X6442 | 44.907 |
| 3YA1848 | 18.5 | |||||
| B800*6.5 | 4 |
Contáctenos rellenando el formulario o por Email: sales@zxcrusher.com
Original manganese liners, eccentric bushings, and bearings ensure perfect fit, maximum wear life, and reliable cone crusher performance.
Our team provides installation guidance, operation training, and troubleshooting assistance to keep your mobile cone crusher running at peak efficiency.
Our global parts network ensures rapid delivery of genuine components, minimizing downtime and production loss.
We provide comprehensive support throughout the entire lifecycle of your equipment. Our service approach ensures long-term reliability and optimized performance for every project.
