The mobile jaw crusher operates on the proven "crank-driven extrusion" principle. The electric motor drives the eccentric shaft through V-belts and pulleys, converting rotational motion into the reciprocating movement of the moving jaw. As the moving jaw approaches the fixed jaw, the toggle plate angle increases, reducing the crushing chamber volume. The material between the two jaw plates is subjected to compression, shearing, and grinding forces. When these forces exceed the material's compressive strength, the material fractures into smaller fragments.

As the moving jaw moves away from the fixed jaw, the toggle plate angle decreases. The pull rod and spring system assists in resetting the moving jaw. The discharge opening widens, allowing crushed material that meets the size requirement to fall out by gravity. Each complete forward-and-backward motion completes one crushing and discharging cycle.

This cycle repeats continuously as the motor keeps running. New material constantly enters from the top feed opening, ensuring continuous flow through the crusher. The mobile jaw crusher is specifically engineered for primary crushing, capable of handling large feed sizes and producing consistent output. Its robust construction ensures reliable performance under the most demanding conditions in mining, quarrying, and construction applications. The mobile design adds flexibility, enabling rapid site-to-site transport and quick setup without complex foundation work.
