1. High-Efficiency Sand Washing: Excellent sand washing efficiency and stable cleaning effect, fully meeting the sand washing needs of large-scale sand and gravel processing.
2. High Cost Performance: Moderate equipment pricing and low comprehensive input cost, balancing operational performance and economic practicality.
3. Water-Saving & Low Loss: Low water consumption during the sand washing process, which effectively reduces the loss of fine sand and stone powder to improve the utilization rate of sand and gravel resources.
4. Easy Maintenance & Durable: Simple overall structural design for convenient daily inspection and maintenance; the bearing device is arranged in isolation from water and materials, greatly reducing the probability of equipment failure, extending the service life, and featuring the operational advantages of high efficiency and energy saving.
Guaranteed Genuine Sand Washer Spare Parts
To ensure your XS Series sand washing plant runs at peak efficiency with zero unexpected downtime, we supply a full range of genuine, factory-direct sand washer spare parts. Every component is manufactured to original equipment manufacturer (OEM) standards, guaranteeing a perfect fit and extended service life.
1. Premium Wheel Buckets & Screen Mesh: We offer heavy-duty steel and polyurethane screen mesh options. Polyurethane screens provide up to 3-5 times longer wear life and exceptional resistance to plugging.
2. Robust Drive System Components: High-quality reduction gears, heavy-duty bearings, and specialized drive shafts designed to withstand wet, muddy, and high-load environments.
3. Impeller & Wear Plates: Thickened, wear-resistant lining plates protect the main structure from continuous sand abrasion, significantly lowering your long-term maintenance costs.
Preventative Maintenance & Wear Optimization
Maximize your return on investment (ROI) with our tailored maintenance solutions. The XS series features an isolated drive system (bearings are separated from water and sand), but regular care ensures maximum output.
1. Customized Wear Part Packages: Based on your material hardness (e.g., river pebble, crushed limestone, granite sand) and daily capacity, we configure customized wear parts backup packages so you always have critical spares on hand.
2. Wear Analysis Services: Our engineers can analyze your spent screens or bucket lips to recommend material upgrades, helping you optimize sand washing efficiency and minimize cost per ton.
1. Feeding & Submerging
The raw sand and gravel are fed into the washing tank. Simultaneously, water is pumped into the pool, submerging the material into a fluid sand-water slurry.
2. Impeller Rotation & Friction
The electric motor drives the impeller rotation via the reduction gearbox. As the large wheel buckets rotate and scoop up the sand, the particles rub intensely against each other, stripping away the surface clay and destroying the moisture vapor layer wrapping the sand.
3. Overflow & Impurity Separation
Clean rinsing water continuously flushes the sand in the buckets. The detached clay and fine impurities float to the surface and are discharged out through the overflow weir, while the heavy, clean sand remains in the buckets.
4. Gravity Dewatering & Discharge
As the wheel lifts the clean sand above the water level, excess water drains back into the tank through the polyurethane screen mesh. This gravity-driven dewatering process ensures low moisture output before the sand is discharged onto the product conveyor belt.
*La capacidad de producción variará en función de los distintos materiales, tamaño de alimentación y otros factores.
| Model | Bucket wheel diameter(mm) | Max feeding size(mm) | Capacity(t/h) | Speed(r/min) | Power(kw) | Overall dimension(L×W×H)(mm) | Weight(t) |
| XS2600 | 2600 | ≤10 | 20-50 | 2.5 | 5.5 | 3550X2080X2650 | 2.67 |
| XS2600II | 2600 | ≤10 | 30-70 | 2.5 | 5.5 | 3550X2080X2650 | 2.9 |
| XS2800 | 2800 | ≦10 | 50-100 | 1.2 | 11 | 3964x2137x2895 | 3.98 |
| XS3200 | 3200 | ≤10 | 80-120 | 1.2 | 15 | 4346x2934x3345 | 7.27 |
| XS3600 | 3600 | ≤10 | 120-180 | 1 | 15 | 4355X4505X3810 | 9.43 |
Contáctenos rellenando el formulario o por Email: sales@zxcrusher.com
Expert engineers can be deployed on-site to guide the foundation layout, mechanical assembly, and water-circuit integration.We don't just sell equipment; we deliver long-term operational reliability. Our global engineering team is ready to provide comprehensive technical support throughout the entire lifecycle of your wheel sand washer.
We offer heavy-duty steel and polyurethane screen mesh options. Polyurethane screens provide up to 3–5 times longer wear life and exceptional resistance to plugging.
Our wheel bucket lips and impellers are reinforced with highly wear-resistant manganese steel or premium alloy, designed to endure continuous abrasion from sharp silica sand and gravel.
We provide comprehensive support throughout the entire lifecycle of your equipment. Our service approach ensures long-term reliability and optimized performance for every project.
